HR-SB504535

Overview
The HANRUIN  Shielding  Box is  wide  frequency  band supporting  range from 600 to 8000 MHz,
and  can  be  applied  to  most of  the  current and future   wireless  communication   technologies
such  as GSM,  WCDMA, WiMAX,  LTE,  GNSS,  Bluetooth,  and Wi-Fi.  Therefore, it can be used for
mobile  device   measurement   using   multi-frequency  bands  without limitations and is  ideal for
mobile device  measurement by maintaining stable and effective shielding performance in all
frequency bands.


Key Features
▌  Easy Opening/Closing of lid
▌  Higher RF Isolation
▌   High Performance RF Absorber lining
▌  Powered by AC / DC Power Filter lines
▌  User Defined & Interchangeable I/O Connector Panels
▌  Designed to test complete systems
▌   Fully customizable Shielded Enclosure
▌  Lightweight Rack Mountable or Tabletop Options
▌  Rugged Stainless Steel Welded Construction
▌  Wireless device testing
▌  Perfect for 802.11 – all series



Specification

Shielding Effectiveness :
≧80dB＠800M~8GHz

Dimension :
Outside : W 560 x D 615 x H 440mm
Inside : W 450 x D 535 x H 380mm
Weight : Approx. 38 Kg
Box color : white
Structure : Galvanized steel plate

Absorber Reflectivity
Frequency / Reflectivity(dB)
500M~8G : -20dB Maximum

I/O Option
User Defined Input / Output Interface Filter Options :
Ethernet - 100M、1G、10G
USB 2.0 & 3.0
AC / DC Power filter
RJ11
Audio
HDMI
AC / DC Power filter
Air ventilation with AC or DC fan­
Waveguide for fiber insertion
ST Fiber connector
RF Ports : SMA, BNC


Filter specification
